| Place of Origin: | Dongguan China |
|---|---|
| ブランド名: | SANNI |
| Material: | Plastic & Metal | Shaft Material: | Plastic |
|---|---|---|---|
| Shaft Length: | 6mm-20mm Normal Or Customized | Resistance Tolerance: | ±20% |
| Power Rating: | 0.05W | Rotational Life: | 10,000 Cycles |
| Dielectric Strength: | 500VAC | Gang: | Single |
| ハイライト: | Plastic metal rotary potentiometer,Rotary potentiometer temperature range -25 to 85°C,Potentiometer for electronic control panels |
||
The Rotary Potentiometer is a highly versatile and reliable component widely used in electronic circuits for precise control of voltage and current. With a compact dimension of 9mm, this potentiometer is designed to fit seamlessly into a variety of applications, making it an ideal choice for both professional engineers and hobbyists. Its small size does not compromise its functionality, as it offers excellent performance and durability in a range of environments.
One of the standout features of this Rotary Potentiometer is its mounting type. It comes with a Through Hole/DIP Mount design, which ensures secure and stable installation on printed circuit boards (PCBs). This mounting style not only provides mechanical strength but also facilitates easy soldering and replacement, making it a practical option for mass production as well as prototyping. The Through Hole/DIP Mount ensures compatibility with standard PCB layouts, enhancing its adaptability across different electronic devices.
This potentiometer is equipped with a shaft that is available in multiple types including Round, Flat, and Knurled. This variety allows users to select the most suitable shaft type depending on their specific application needs. The Round shaft offers smooth and continuous rotation, ideal for fine adjustments. The Flat shaft provides better grip and control, reducing the chances of accidental slips during manual adjustment. Meanwhile, the Knurled shaft features a textured surface that enhances grip, making it easier to operate even in environments where precision handling is required. This flexibility in shaft design makes the Rotary Potentiometer a highly customizable Rotary Manual Adjustment Tool.
In terms of electrical performance, this potentiometer boasts an insulation resistance of 100MΩ minimum. This high insulation resistance ensures minimal leakage current and excellent electrical isolation between the resistive element and the casing. As a result, the potentiometer maintains stable performance and reduces the risk of electrical faults, making it suitable for sensitive and high-precision circuits.
The resistance tolerance of this Rotary Potentiometer is ±20%. While this tolerance might be broader compared to some precision potentiometers, it is well-suited for applications where moderate accuracy is sufficient. This tolerance range ensures that the potentiometer can reliably function as a Rotary Voltage Divider Potentiometer, effectively dividing voltages within a circuit according to the user’s adjustments. Its ability to act as a voltage divider makes it indispensable in tuning circuits, volume controls, light dimmers, and other variable resistance applications.
As a Rotary Linear Variable Resistor, this potentiometer provides a smooth and linear change in resistance as the shaft is rotated. This linearity is crucial for applications where precise control over electrical parameters is necessary. Whether used in audio equipment, measurement instruments, or control panels, the linear response of this potentiometer guarantees predictable and repeatable adjustments, enhancing the overall performance and user experience of electronic devices.
In summary, this Rotary Potentiometer combines compact size, versatile mounting options, multiple shaft types, high insulation resistance, and a practical resistance tolerance to deliver a dependable and efficient Rotary Manual Adjustment Tool. Its role as a Rotary Linear Variable Resistor and Rotary Voltage Divider Potentiometer makes it a fundamental component in numerous electronic applications. Whether you are designing a new circuit or replacing an existing potentiometer, this product offers the quality and adaptability you need for optimal performance.
| Shaft Length | 6mm-20mm Normal Or Customized |
| Dielectric Strength | 500VAC |
| Resistance | 300Ω-3MΩ |
| Mounting Type | Through Hole / DIP Mount |
| Power Rating | 0.05W |
| Shaft Type | Round / Flat / Knurled |
| Gang | Single |
| Terminal Type | PCB Lug |
| Dimension | 9mm |
| Resistance Tolerance | ±20% |
The SANNI Rotary Potentiometer, originating from Dongguan, China, is a versatile and reliable component widely used in various applications and scenarios. As a Rotary Linear Variable Resistor, this device is designed to provide precise control over electrical signal levels, making it essential in both industrial and consumer electronics. Its compact dimension of 9mm and single gang configuration allow it to fit seamlessly into tight spaces, enhancing its adaptability across different environments.
One of the primary applications of the SANNI Rotary Potentiometer Device is in audio equipment. It is commonly used as a volume control knob due to its smooth and accurate adjustment capabilities. The 6mm shaft diameter, which can also be customized, ensures compatibility with a wide range of knobs and interfaces, providing users with ergonomic and tactile control. Additionally, the PCB lug terminal type allows for easy and secure mounting on printed circuit boards, facilitating efficient assembly in mass production.
In industrial settings, the Rotary Voltage Divider Potentiometer serves as a critical component in machinery control panels, enabling operators to fine-tune parameters such as speed, temperature, and pressure. Its robust construction, combining plastic and metal materials, guarantees durability and long service life even under demanding conditions. The device’s precision and reliability make it suitable for use in automation systems, robotics, and instrumentation where accurate variable resistance is crucial.
Moreover, the SANNI Rotary Potentiometer is employed in automotive electronics for adjusting dashboard controls and sensor calibrations. Its small size and sturdy build make it ideal for integration into compact vehicle control modules. The potentiometer’s ability to provide linear variable resistance ensures consistent and predictable performance, which is vital for safety-critical applications.
In summary, the SANNI Rotary Potentiometer Device is an indispensable component across a variety of application occasions and scenarios. Whether used as a Rotary Linear Variable Resistor in audio devices, a Rotary Voltage Divider Potentiometer in industrial machinery, or a precise control element in automotive systems, it offers a perfect balance of size, durability, and functionality. Originating from Dongguan, China, and featuring a PCB lug terminal type, 6mm customizable shaft diameter, plastic and metal construction, and a compact 9mm dimension, this single gang potentiometer is engineered to meet diverse operational needs with exceptional performance.
At SANNI, based in Dongguan, China, we offer specialized product customization services for our Rotary Potentiometer products. Our Rotary Variable Resistor can be tailored to meet your specific needs, with a compact dimension of 9mm ensuring versatile application. We provide customization options that maintain an insulation resistance of 100MΩ minimum, ensuring reliable performance in various electrical environments.
Our Rotary Electrical Potentiometer is designed to operate efficiently within a temperature range of -25℃ to 85℃, making it suitable for diverse industrial applications. Customers can choose between Through Hole or DIP Mount mounting types to fit their assembly requirements perfectly. Additionally, our potentiometers comply with a dielectric strength of 500VAC, offering enhanced safety and durability.
As a trusted provider of Rotary Analog Adjustment Devices, SANNI is committed to delivering high-quality customized solutions that cater to the unique demands of your projects. Contact us to discuss your specifications and let us help you achieve the ideal rotary potentiometer for your applications.
